4G Solar Vehicle Tracker for Containers or Hidden in Vehicles, with Long Battery Life

4G Solar Vehicle Tracker for Containers or Hidden in Vehicles, with Long Battery Life

4G Vehicle Tracker With Internal Antennas

The LL303 is a solar-powered 4G GPS tracker designed for managing construction vehicles and vessels. With a solar panel, magnetic charger, and IP67 waterproof rating, this device is ideal for a variety of deployments requiring long standby times and continuous optimal performance. LTE communication with GSM (2G) fallback ensures a solid connection in almost any situation. In addition to these features, multiple operating modes, diverse peripheral accessories, and a suite of event-triggered alerts will make the LL303 a valuable part of your fleet management strategy.

GNSS

GPS+BDS+LBS positioning system

Positioning accuracy ＜2.5m CEP

Tracking sensitivity -165dBm

Acquisition sensitivity -148dBm

TTFF (Open Sky) Average hot start ≤1 sec.

Average cold start time ≤32 sec.

Mobile

LTE Cat 1/GSM communication network; LTE Cat M1/Cat NB2

Frequency LL303-L

LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B20/B28

LTE-TDD: B40

GSM: B2/B3/B5/B8LL303-E

LTE-FDD: B1/B3/B5//B7/B8/B20/B28

LTE-TDD: B38/B40/B41

GSM: B2/B3/B5/B8LL303-A

Cat M1: B2/B4/B5/B12/B13/B25/B26/B66

Cat NB2: B2/B4/B5/B12/B13/B25/B66

GSM: B2/B3/B5/B8

Feeding

Industrial-grade 10,000 mAh/3.7V lithium-polymer battery

Solar powered 5V/400mA (Standard operating voltage/current @STC)

STC: Direct illumination with a 38,000 lux halogen lamp on the test bench.

5V/2A magnetic charger

Working modes Mode 1: Timed positioning mode

Mode 2: Intelligent positioning mode

Mode 3: Battery saving mode

Standby time Up to 2 years in battery saving mode

Interface

LED Indication Cell (Green), Power (Red)

Nano-SIM SIM

Tamper-proof Hall effect sensor

Physical specifications

Dimensions 203x122x33mm

Weight 548g

Operating environment

Operating temperature -20℃ to +70℃

Operating humidity 5%～95%, non-condensing

IP67 protection rating

Characteristics

Sensors Accelerometer, Hall effect sensor

Scenarios Low battery alert, Tamper alert, Vibration alert

Bluetooth BLE 5.0

RFID 2.4 GHz

Special for containers
