AC5400 MU-MIMO Tri-Band Gaming Router 1 x 10/100/1000Mbps WAN Port & 8 x 10/100/1000Mbps LAN Ports, 2 x USB 3.0 Port & 8 x Antennas.

When you’re gaming at the highest settings, it’s imperative that you have impressive processing power. Quad-core means power. With a 1.8GHz 64-bit quad-core CPU, three coprocessors, and 1GB of RAM, the Archer C5400X delivers the raw power to perfectly run all services, threads, and applications to eradicate latency and deliver smooth gameplay.

General characteristics

• 8 10/100/1000Mbps LAN Ports
• 1 10/100/1000Mbps WAN port
• 2 USB 3.0 ports
• 8 High-performance antennas
• Processor - 1.8 GHz quad-core CPU and three co-processors
• Multiple Reliable Connections – MU-MIMO allows the router to achieve 4 times greater efficiency by communicating with up to 4 devices at the same time
• Wireless Standards IEEE 802.11n/g/b 2.4GHz and IEEE 802.11ac/n/a 5GHz
• 2.4GHz: up to 1000Mbps
• 5GHz: up to 2167Mbps
• 64/128-bit WEP, WPA / WPA2, WPA-PSK/ WPA2-PSKEl encryption
• WMM, Bandwidth Control
• Virtual Server, Port Triggering, UPnP, DMZ
• Parental Control, Local Management Control, Host List, Calendar Access, Rule Management
• DoS, SPI Firewall, IP Address Filter/MAC Address Filter/Domain Filter IP and MAC Address Binding
• Reset button
• Guest network
• VPN Server

Physical and electrical characteristics

• Power Supply 100-240V 50/60Hz
• Dimensions (WXDXH) 11.3 X 11.3X 7.2 in.(with antennas)
• Operating Temperature: 0℃~40℃ (32℉~104℉)
• Storage Temperature: -40℃~70℃ (-40℉~158℉)
• Operating Humidity: 10%~90% non-condensing
• Storage Humidity: 5%~90% non-condensing

Advanced Features

• Working Mode (Router Mode or AP Mode)
• Wireless programmer
• Time machine
• TP-Link DDNS
• Parental Controls / Antivirus / QoS
• IPv6
• VPN Server (OpenVPN and PPTP servers)
• NAT Forwarding (DMZ/UPnP...)
• Link Aggregation (WAN/LAN)
• Airtime Fairness
• SmartConnect
• Authentication portal for guest Wi-Fi

Includes

• AC5400 Tri-Band MU-MIMO Gigabit Archer C5400 Wireless Router
• Power supply unit
• Ethernet cable
• Quick Installation Guide
