Antena blindada de alto rendimiento con supresión al ruido de 2 ft, 4.9-6.4 GHz, Ganancia 30 dBi con SLANT de 45 ° y 90 °, Conectores N-hembra, montaje con alineación milimétrica.

High performance shielded antenna with 2 ft noise suppression, 4.9-6.4 GHz, 30 dBi gain with 45° and 90° SLANT, N-female connectors, millimeter alignment mounting.

$4,053,428
Skip to product information
Antena blindada de alto rendimiento con supresión al ruido de 2 ft, 4.9-6.4 GHz, Ganancia 30 dBi con SLANT de 45 ° y 90 °, Conectores N-hembra, montaje con alineación milimétrica.

High performance shielded antenna with 2 ft noise suppression, 4.9-6.4 GHz, 30 dBi gain with 45° and 90° SLANT, N-female connectors, millimeter alignment mounting.

$4,053,428
Shipping calculated at checkout.
Marca
NetPoint
Referencia / SKU
NPX1GEN3
Disponibilidad
Agotado por ahora
Descripción y especificaciones

High performance shielded antenna with 2 ft noise suppression, 4.9-6.4 GHz, 30 dBi gain with 45° and 90° SLANT, N-female connectors, millimeter alignment mounting.

Differentiators:

  • The widest frequency range on the market.
  • Connectivity with other brands. Ubiquiti, Mimosa, Cambium, etc.
  • 45° Slant-type polarization to reduce noise levels.
  • Fine-tuned assembly, highly robust and stable.
  • Ideal antenna for ISP
  • Antenna for CCTV deployments

Electrical Specifications:

  • Frequency Range: 4.9 - 6.4 GHz
  • Antenna Type: Parabolic
  • Connector Type: N - Female
  • Gain 30 dBi
  • VSWR: < 2
  • HPOL beamwidth: 5.5°
  • VPOL beamwidth: 5.0°
  • Return loss: 9.54 dB
  • ISO: 30 dB
  • F/B Radio: 39 dB
  • Polarization: Dual

Mechanical Specifications:

  • Wind resistance speed: 200 km/hr
  • Azimuth Adjustment: 360°
  • Elevation Adjustment: ±15°
  • Suggested mast diameter: 50 - 70, 100 - 114 mm
  • Operating Temperature: -45 to + 60
  • Gross weight 6.5 kg

Note: For correct installation always use vulcanized tape.

The jumpers included with the antenna are compatible with the following radios: C5c, AF5XHAD, R5ACLITE, RP5ACGEN2, LTUROCKET, RP5ACGEN2, EPMP-3K, FORCE300-CSM, C050940C121A, C050910C161A, EPMP-3KL

    High-precision mounting, Dual polarization, Includes N-Male to reverse SMA Male jumper, Noise suppression, Super lightweight
