• Expansor de 8 Zonas Cableadas / Conexión Bus Speed-X / 2 Salidas de Relevador / Compatible con paneles AX Hybrid Pro
1 5

HIKVISION

8 Wired Zone Expander / Speed-X Bus Connection / 2 Relay Outputs / Compatible with AX Hybrid Pro panels

8 Wired Zone Expander / Speed-X Bus Connection / 2 Relay Outputs / Compatible with AX Hybrid Pro panels

$162.698 COP
$177.951 COP $162.698 COP
Sale Sold out
Shipping calculated at checkout.

8 Wired Zone Expander / Speed-X Bus Connection / 2 Relay Outputs / Compatible with AX Hybrid Pro panels

Main features:
  • Supports 8 alarm zones (inputs for wired sensors).
  • Operating voltage: 9-15 VDC.
  • Current consumption: 119 mA
  • Output voltage: 9-15 VDC (same as input)
  • Output current: up to 500 mA
  • Operating temperature: -10°C to 40°C.
  • Dimensions: 110 x 155 x 31 mm.
  • Weight: 252.5 grams.
Highlighted Features:
  • It has 2 voltage alarm outputs (wet contact).
  • It has 2 Speed-X bus connections, one for communication with the panel and another for connecting another expander.
  • Sensor monitoring by means of end-of-line resistor.
  • The maximum distance from expander to expander is 900 m (maximum 7 with 64-zone panel).
  • Binary address setting (by dip-switch)
  • Compatible only with DSPHA48EP and DS-PHA64-LP alarm panels

    Speed-X Technology, Wide compatibility of wired sensors, Longer communication distance

487 in stock

MODELO: DS-PM1-I8O2-H
