TELTONIKA
Uninterruptible Power Supply 2300 mAh 17 Wh
Uninterruptible Power Supply 2300 mAh 17 Wh
Regular price
$635.705 COP
Regular price
$785.422 COP
Sale price
$635.705 COP
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
Uninterruptible Power Supply 2300 mAh 17 Wh
| ENERGY | |
|---|---|
| Connector | 4-pin industrial DC power socket |
| Input power/maximum charging current | Charger: max. 4W/300mA (maximum battery charging current) |
| Input voltage range | 9 - 30 VDC |
| Ingress protection | Reverse polarity protection, Overvoltage protection |
| Output voltage in step mode | 9 - 30 VDC |
| Output voltage in battery mode | 12 VDC |
| Exit protection | Overcurrent protection 3A |
| Maximum output power/current in battery mode | 22 W/1.8 A |
| Battery capacity | 2300 mAh 17 Wh |
| PHYSICAL INTERFACES (PORTS, LEDS, BUTTONS) | |
|---|---|
| POWER INPUT | 1 x 4-pin DC connector |
| No electricity | 1 x 4-pin DC connector |
| Status LED | 1 x IN PWR LED, 1 x OUT PWR LED, 4 x Power Status LEDs |
| Change | On/Off Slide Switch |
| ALARM OUTPUT | |
|---|---|
| Alarm output | 1 active HIGH output, max output 12 V, 2.5 mA |
| GENERAL CHARACTERISTICS | |
|---|---|
| lithium cells | 2 x 18650 lithium-ion cells |
| Supported devices | RUT2xx, RUT95x, RUT3xx, RUTXxx, TRB14x, TRB2xx, TSW110, TCR100 |
| PHYSICAL SPECIFICATION | |
|---|---|
| Housing material | Aluminum housing |
| Dimensions (W x H x D) | 100x30x85mm |
| Weight | 315g |
| Mounting options | DIN rail, mounting on a flat surface |
| OPERATING ENVIRONMENT | |
|---|---|
| Operating temperature | 0 °C to 45 °C |
| REGULATORY AND TYPE APPROVALS | |
|---|---|
| Regulator | CE/RED, UKCA, EAC |
- Battery capacity: 2300mAh, Alarm output for RUT
Share
Out of stock
MODELO: BAT120
