hAP ax2 Wireless Wi-Fi 6 Router
It's time to boost your home network with the grid Generation 6 wireless And our latest addition to the beloved hAP series. hAP ax2 has everything you could need in a main home access point, and more! Forget endless reviews and comparisons—this is the perfect device for 99% of homes.
The wireless signal is now stronger than ever. These are the two main ingredients for the success of hAP ax: a state-of-the-art dual-band 4 to 4.5 dBi dual-chain radio and the 802.11ax standard with Wave2 support. Let's compare it to the previous generation: depending on your overall setup, that means up to 40% faster on 5 GHz and up to 90% faster on the 2.4 GHz spectrum!
Some might ask: why do we need higher wireless speeds? Well, countless use cases have been impossible or difficult to implement in the past. For example, working with large media files over the wireless network, without having to download and upload everything. Do you really have time to wait? Grab an ax2 hAP and save more time for the essentials in life!
The modern quad-core CPU running at 864MHz combined with a solid GB of RAM packs a punch when it comes to heavy operations like complex firewall rules, IPsec hardware encryption, using multiple threads, or experimenting with RouterOS' more advanced features. And with the addition of WPA3 advanced encryption support, you're more secure than ever.
Like previous models, hAP ax2 can be mounted vertically, horizontally, or even on a wall, without sacrificing a strong signal.
With so many products and features on the market, even an experienced user can get confused. So it's time for a Simple truth for a simple choice : you can’t go wrong with an ax2 hAP in most homes.
Specs
Details | |
---|---|
Product code | C52iG-5HaxD2HaxD-TC |
Architecture | ARM 64-bit |
CPU | IPQ-6010 |
CPU core count | 4 |
Nominal CPU frequency | 864 MHz |
RouterOS License | 4 |
Operating system | RouterOS |
RAM size | 1 GB |
Storage size | 128 MB |
Storage type | NAND |
MTBF | Approximately 100,000 hours at 25°C |
Room temperature tested | -40 °C to 50 °C |
Wireless capabilities
Details | |
---|---|
2.4 GHz Max Wireless Data Rate | 300 Mbit/s |
Number of 2.4 GHz wireless chains | 2 |
2.4 GHz wireless standards | 802.11b/g/n/ax |
Antenna gain dBi for 2.4 GHz | 4.5 |
2.4GHz Wireless Chip Model | QCN-5022 |
2.4 GHz wireless generation | Wi-Fi 4 |
5GHz Max Wireless Data Rate | 867 Mbit/s |
Number of 5 GHz wireless chains | 2 |
5 GHz Wireless Standards | 802.11a/n/ac/ax |
Antenna gain dBi for 5 GHz | 4 |
5GHz Wireless Chip Model | QCN-5052 |
5 GHz wireless generation | Wi-Fi 6 |
AC speed | AC1200 |
Ethernet
Details | |
---|---|
10/100/1000 Ethernet ports | 5 |
Number of 1G Ethernet ports with PoE output | 1 |
Feeding
Details | |
---|---|
Number of DC inputs | 2 (DC connector, PoE-IN) |
DC jack input voltage | 12-28 V |
Maximum energy consumption | 27 W |
Maximum power consumption without accessories | 12 W |
Cooling type | Passive |
PoE in | Passive PoE |
PoE on input voltage | 18-28 V |
PoE-out
Details | |
---|---|
PoE-out ports | Ether 1 |
PoE out | Passive PoE |
Maximum output per port output (18-30 V input) | 600 mA |
Maximum total (A) | 0.6 A |
Total output current | 0.6 |
Total output power | 16.8 W |
Certification and approvals
Details | |
---|---|
Certification | CE, FCC, IC, EAC, ROHS |
Others
Details | |
---|---|
Mode button | Yeah |
Parts included
