• TV Doorphone Function.
• 2 MP camera (1920 X 1080).
• IR hidden 3m.
• Supports 17 street fronts (1 main and 16 ext.)
• H.264 encoding.
• WDR, BLC, DNR.
• 2 Relay Outputs (Supports 2 Doors)
• Omnidirectional Audio.
• Network: 10/100 Mbps Self-Adaptive Ethernet
• Configurable via iVMS4200.
• 10,000 PROX EM cards (using DS-KD-E ).
• Warranty: 2 years

Optional modules ( Maximum 8 )

• DS-KD-E : PROX EM card reader (125 Khz).
• DS-KD-KP : Numeric keypad for dialing or pin access.
• DS-KD-KK : 6 additional call buttons.
• DS-KD-IN : Call/opening status indicator.
• DS-KD-BK : Blind cover

• Operating voltage: 12 VDC or IEEE 802.3af PoE (Recommended DS-3E0105P-E/M switch)
• Power consumption: 10 W
• Protection level: Exterior IP65.
• Material: Aluminum.
• Operating Temperature:-40° C to +60° C (-40° F to 140° F)
• Humidity: 10 to 95%
• Dimensions: 98 mm × 99.8 mm × 43.9 mm (3.86' × 3.93' × 1.73').

The multi-apartment system is recommended for residential buildings, apartments, and offices, with access control via an EM card, code, or remote opening.

It is not possible to add it directly to Hik-Connect, a Hikvision IP monitor is required for its operation.

Compatible monitors:

• DS-KH6220-LE1 (local only, no call to the App).
• DS-KH6320-WTE1
• DS-KH8520-WTE1
• DS-KH9510-WTE1
• DS-KH9310-WTE1

Supports 100 departments in total (with DS-KD-KP )

Supports 6 monitors per department (1 main monitor and 5 extensions). They all ring at the same time.

It supports 17 street fronts in total (1 main and 16 slaves).
