Dual G/EPON ONU with Wi-Fi AC + 1 CATV Port + 2 Gigabit Ports + 1 SC/APC Port, Up to 1200 Mbps

Dual G/EPON ONU with Wi-Fi AC + 1 CATV Port + 2 Gigabit Ports + 1 SC/APC Port, Up to 1200 Mbps

$203.976 COP
$223.099 COP $203.976 COP
Sale Sold out
Shipping calculated at checkout.

Dual G/EPON ONU with Wi-Fi AC + 1 CATV Port + 2 Gigabit Ports + 1 SC/APC Port, Up to 1200 Mbps

Main features:
  • Dimensions: 178mm × 120mm × 30mm (length × width × height).
  • Frequency range: 2.400-2.483 GHz and 5.150-5.825GHz .
  • Gain 5 dBi.
  • Multiple SSID.
  • Power: 2.4 GHz: 23 dBm / 5 GHz: 27 dBm.
  • Security: WEP / WPA-PSK (TKIP) / WAP2-PSK (AES)
  • Dual Giga Ethernet port.
  • Wavelength: TX: 1310 nm & RX: 1490 nm.
  • Management: OAM/OMCI, Telnet, Web, TR069 and HGU V-SOL OLT.
Physical and Electrical Characteristics:
  • Power supply: 12 Vdc / 1 A ( Includes DC power supply ).
  • 2 RJ45 10/100/1000 Mbps ports.
  • 1 CATV RF port
  • 1 USB 3.0 port
  • Maximum consumption: ≤12W.
  • Weight: 0.3 Kg.
  • Operating temperature: 0 ℃ ～ + 50 ℃.
Network Features:
  • Dual 10/100/1000Mbps network ports.
  • 1 PON port (EPON/GPON) .
  • SC/UPC connector
  • EPON PX20+.
  • GPON Class B+.
  • CATV 1550nm RF Interface
  • Receiving sensitivity: ≤-27dBm.
  • Connection mode: Bridge, Router & Bridge/Router mixed
  • IP address assignment: PPPoE client, DHCP client and Static IP.
  • Supports VLANs.

Gigabit Fiber XPON CATV ONT

XPON | Gigabit-LAN ​​| CATV RF | USB3.0

EasyMesh: Smart, Extended Coverage Home WiFi

Support IPv6 and MU-MIMO Technology

Say goodbye to network lag, online multiplayer without lag

AC1200 Dual Gigabit Interfaces for
Gigabit Broadband Access Applications

CATV with AGC

Remote Control CATV On/Off

    XPON Dual Mode, Supports EasyMesh Protocol, Dual Band WiFi 5, Up to 1200Mbps

500 in stock

MODELO: V2802-ACT
