• ONU Dual G/EPON con Wi-Fi en 2.4 GHz + 1 puerto LAN Gigabit, hasta 300 Mbps vía inalámbrico
1 4

V-SOL

Dual G/EPON ONU with 2.4 GHz Wi-Fi + 1 Gigabit LAN port, up to 300 Mbps via wireless

Dual G/EPON ONU with 2.4 GHz Wi-Fi + 1 Gigabit LAN port, up to 300 Mbps via wireless

$93.686 COP
$102.469 COP $93.686 COP
Sale Sold out
Shipping calculated at checkout.

Dual G/EPON ONU with 2.4 GHz Wi-Fi + 1 Gigabit LAN port, up to 300 Mbps via wireless

ONU EPON/GPON Wi-Fi 2.4 GHz

Up to ' 300 Mbps ' via Wi-Fi

  • 1 RJ45 10/100/1000 port
  • 1 SC/UPC PON port
  • Supports EPON PX20 / GPON Class B+
  • Optical receiving sensitivity: ≤-27dBm
  • Distance of 20 km
  • 2 external 5dBi antennas
  • IEEE802.11b/g/n Wi-Fi standards
  • Wi-Fi power: 17dBm
  • MIME
  • Local management software .
  • Remote management software .
  • Management from mobile APP .

Main features:
  • 120mm × 78mm × 30mm （Length × width × height)
  • Maximum consumption: ≤6W
  • Management: WEB, Telnet, CLI and V-SOL OLT
  • Multiple SSID
  • Wavelength: Tx 1310 nm, Rx 1490 nm / Tx 1490 nm, Rx 1550 nm
Physical and Electrical Characteristics:
  • Power supply 12 Vdc, 0.5 A ( Includes DC power supply ).
  • 1 RJ45 port
  • Wi-Fi 2.4 GHz
  • Operating temperature: -30 ℃ ～ + 50 ℃
  • Storage temperature: -30℃ to +70℃
Network Features:
  • 1 Gigabit Ethernet RJ45 port
  • Supports IGMP Snooping
  • Supports VLAN Tag/Untag
  • IPv4/IPv6
  • Supports DHCP / PPPOE / Static IP
  • Bridge mode or router mode

Application diagram

VSOL 1GE WiFi XPON ONT V2801RGW

XPON Dual Mode | Powerful Firewall | 2.4GHz 802.11b/g/n

Powerful features

High working temperature design

Staytable Connection

Easy to install, saves space

Other features

    2.4 GHz WiFi, GEPON/EPON, 2 5 dBi Antennas, Up to 300 Mbps via WiFi, Mobile APP Management, Remote Management Software

500 in stock

MODELO: V2801-RGW
