• Video compression: H.265+ / H.265 / H.264+ / H.264.
• Supports USB mouse to operate (included).
• Supports 4 HDDs up to 10TB. (not included).
• Supports local or remote calendar search.
• Supports ANR technology with HIKVISION IP camera when the network is disconnected.
• Supports DDNS (Hik-Connect, DynDNS, No-IP, etc.).
• Supports Hik-Connect P2P (Hik-Connect).
• IVMS-4200 client software (free).

Processing capacity and network functions:

• Input throughput: 200 Mbps.
• Output throughput: 160 Mbps.
• 1 RJ-45 network port: 10 / 100 / 1000 Mbps. (LAN)
• 16 Built-in 802.3 af/at PoE Ports (30 W max per port).
• Maximum total supply capacity on PoE ports: 200 W.

• Dimensions: 445 x 400 x 75 mm.
• Power supply: 100 to 240 Vac / 20 W (without hard drives).
• Operating temperature: -10°C to 55°C.
• Weight: 5 Kg without HDD.
• Warranty: 2 years.
• Compatible with GAB-VID2-R2 metal cabinet.

Recording and Viewing Functions:

• Multi-zone motion detection.
• Digital zoom in viewing and recording.
• Dual stream (main stream and sub stream).
• Supports fast forward, slow forward, frame by frame, etc.
• Supports SMART hard drive technology
• Supports multiple recording types, including real-time, manual recording, motion detection, motion detection and alarm, motion detection or alarm.
• Supports cyclic (overwrite) and non-cyclic recording.

• HDMI Output: 4K, 1080p, 720p.
• VGA output: 1080p, 720p.
• Independent HDMI and VGA output.
• Audio Input: 1 Channel.
• Audio Output: 1 Channel.
• Alarm Input: 16.
• Alarm Output: 4.
• Supports two-way audio (two-way audio).

Recording Resolution per Channel (recommended with H.265):

• 2 Megapixel: 8 Channels @ 30 IPS.
• 4 Megapixel: 8 Channels @ 30 IPS.
• 5 Megapixel: 8 Channels @ 30 IPS.
• 8 Megapixel (4K): 8 Channels @ 30 IPS.
• Synchronous playback on channels: 16 Channels.

• SUPPORTS CAMERAS WITH ACUSENSE (False Alarm Filter):

• With ACUSENSE technology we can avoid false alarms such as movement of trees, animals, etc.
• By activating ACUSENSE technology, it only detects human bodies and vehicles to truly detect important events and thus eliminate false alarms.
• Supports up to 16 channels with ACUSENSE using cameras: DS-2CD3XX / DS-2CD2XX3G2 (which support ACUSENSE).
