• Maximum resolution: 5 Megapixel ( 2560 x 1920).
• Minimum illumination: color 0.017 Lux @ (F2.25, AGC ON)
• Minimum illumination: B/W 0 Lux with IR
• True Day/Night (ICR filter).
• Focal length: 1.05 mm (viewing angle 180° wall / 360° ceiling)
• Infrared distance: 8 mts IR.
• Normal functions: WDR / 3D DNR / Area intrusion / Line crossing.
• Compression: H.265+ / H.265 / H.264+ / H.264.
• Compatible with HikConnect platform ( https://appstore.hikvision.com/ ).

• Power: 12 Vdc / PoE 802.3 af / 6.5 W.
• Operating temperature: -30°C to 50°C / Humidity at 95% maximum.
• Indoor use.
• Vandal-proof IK10.
• Dimensions: Ø 110.8 × 84.7 mm
• Weight: 530 grs.
• Warranty: 2 years.

Optional accessories:

• Indoor Wall Mount: DS-1294ZJ
• Tilted Ceiling Mount: DS-1281ZJ-DM27
• Extendable Pendant Mount: DS-1297ZJ
• Indoor Pendant Mount: DS-1299ZJ

• Main Stream:
  • 60 Hz: 30 fps（2560 × 1920, 2048 × 1536, 1280 × 960）
  • 50 Hz: 25 fps（2560 × 1920, 2048 × 1536, 1280 × 960）

• Sub Steam:
  • 50 Hz: 25 fps (640 × 480)
  • 60 Hz: 30 fps (640 × 480)

• Multiple views (not applicable to NVR) live as IVMS-4200 program.

Audio Inputs and Outputs / Alarms / Network:

• Alarm inputs: 1.
• Alarm outputs: 1 (24 Vdc, 30 mA).
• Audio inputs: 1.
• Audio outputs: 1.
• Network port: 1 ( 10/100 Mbps / PoE 802.3 af ).
• Micro SD storage up to 256 GB / ANR (Automatic Network Recovery).
• Supports ONVIF/ISAPI/CGI.
