8 Megapixel NVR (4K) / 8 IP channels / 8 PoE+ ports / 2 hard drive bays / 4K HDMI / 300 m PoE switch / 2.0 tracking

• Video compression: H.265+ / H.265 / H.264+ / H.264.
• Supports USB mouse to operate (included).
• Supports 2 HDDs up to 8TB. ​​(not included).
• Supports local or remote calendar search.
• Supports DDNS (Hik-Connect / DynDNS / No-IP).
• Supports Hik-Connect P2P.
• Supports remote access via phone: Android, iPhone, iPad (IVMS-4500 / Hik-Connect).
• Support for IE, Mozilla, Safari, Chrome (ietab) browsers.
• iVMS-4200 Client Software (Free).
• Supports multiple brands such as: AXIS, ONVIF, PANASONIC, PSIA, SAMSUNG, ACTi, SANYO, ZAVIO, VIVOTEK among others.

Processing capacity and network functions:

• Input throughput: 80 Mbps.
• Output throughput: 80 Mbps.
• 1 10/100 Mbps network port. (LAN)
• 8 Built-in 802.3 at PoE+ Ports (Up to 30W per port, total PoE 80W).
• When enabling EXTEND mode, the bandwidth will be 10Mbps and the power supply must not exceed 8W maximum per port.
• Download and playback of recorded files on the NVR over the network.
• Supports remote download of NVR alarm log.
• Remote parameter configuration.

• Dimensions: 385 × 315 × 52 mm. (1 rack unit).
• Power: 100 to 240 VAC max (48 VDC / 2.5 A) / 15 W without HDD and with PoE disabled.
• Operating temperature: -10°C to 55°C (14°F to 131°F).
• Work in humidity: 10% to 90%.
• Weight: 2.6 Kg without HDD.
• Warranty: 2 years.

• Video output on HDMI: 4K (4096 x 2160) / 30 Hz, 4K (3840 x 2160) / 30 Hz, 2K (2560 x 1440) / 60 Hz, 1920 x 1080 / 60 Hz, 1600 x 1200 / 60 Hz, 1280 x 1024 / 60Hz, 1280 x 720 / 60Hz.
• VGA Video Output: 1920 × 1080 / 60 Hz, 1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz
• Independent HDMI and VGA output.
• Audio Input: 1 Channel (two-way audio).
• Audio Output: 1 Channel (two-way audio).
• External recording: Not supported.
• SATA disk capacity: 2 HDDs up to 8TB.
• e-SATA Support: Not supported.
• Disk Array: Not supported.

Recording and Viewing Functions:

• Multi-zone motion detection 2.0 up to 4 channels.
• Digital zoom in viewing and recording.
• Dual stream (main stream and sub stream).
• Supports fast forward, slow forward, frame by frame, etc.
• Supports SMART hard drive technology
• Supports multiple recording types, including real-time recording, manual recording, video recording, video recording and alarm, and video recording or alarm.
• Supports cyclic (overwrite) and non-cyclic recording.

• 2 Megapixel: 6 Channels@30 IPS
• 4 Megapixel: 3 Channels@30 IPS.
• 8 Megapixel (4K): 1 Channel@30 IPS.
• Synchronous playback on channels: 8 Channels.
