30 dB In-Line Attenuator, 2 W Maximum, CD-4 GHz, N Male-Female Connectors.

30 dB In-Line Attenuator, 2 W Maximum, CD-4 GHz, N Male-Female Connectors.

30 dB Bidirectional Attenuator.

• Attenuation: 30 dB.
• Power: 2 Watt.
• Frequency range: From CD to 4 GHz.
• Connectors: N Male-Female.
• Impedance: 50 Ohm.
• VSWR: 1:1.10 (CD-1 GHz), 1:1.25 (1-4 GHz).
• PIM: -110 dBc Min.
• Operating Temperature: -40 ºC to 40 ºC.
• Humidity: 95% non-condensing.
• Material: Tri-metal.
• Cooling Method: Dry by Convection.
• Operating Position: Any, Bidirectional.
• Dimensions: 61 mm (Length) x 21 mm (Diameter).
• Weight: 88 gr.
