16-Port 10/100/1000 Mbps Gigabit Unmanaged Switch, with Extended Mode for Distances up to 200 m

16-Port 10/100/1000 Mbps Gigabit Unmanaged Switch, with Extended Mode for Distances up to 200 m

$370.302 COP
$446.563 COP $370.302 COP
Sale Sold out
Shipping calculated at checkout.

16-Port 10/100/1000 Mbps Gigabit Unmanaged Switch, with Extended Mode for Distances up to 200 m

Plug & PlaySelf-negotiation10M/100M/1000MGiant frameAuto MDI/MDI-X

VLAN Isolation Mode

Port-based helps prevent multicast or broadcasts from connected clients from influencing each other.

Extended Mode

It operates per port at 10 Mbps duplex operation, but can transmit data at a distance of up to 200 meters, exceeding the regulated limit of 100 m.

Hardware specifications
Hardware version 9
10/100/1000BASE-T MDI/MDIX ports 16
Throughput (packet per second) 23.8Mpps
Switch fabric 32 Gbps
Weight 1.8 kg
Power consumption/dissipation 9.4 Watts/32 BTU
Energy requirements 100~240 VAC, 0.16 A, 50-60 Hz
Dimensions 440 x 208 x 44mm, 1U height
Change the processing scheme Store and Forward
Address table 8K tickets
Jumbo package size 9K
Flow control Backpressure for half duplex
IEEE 802.3x Pause Frame for Full Duplex
Dip switch

Selecting the operating mode:

Standard, Flow control off, VLAN, Extend　
Regulatory compliance FCC Part 15 Class A, CE

Compliance with standards

IEEE 802.3 (Ethernet)
IEEE 802.3u (Fast Ethernet)
IEEE 802.3ab (Gigabit Ethernet)
IEEE 802.3x (Full Duplex Flow Control)
IEEE 802.3az Energy Efficient Ethernet (EEE)
Operating temperature Operating temperature: 0~50 degrees C
Relative humidity: 5% to 95% (non-condensing)
Storage temperature Temperature: -10~70 degrees C
Relative humidity: 5% to 95% (non-condensing)

Package contents

- 1 GSW-1601 Switch

- 1 Voltage supply power cable

- 2 Rack mount

- 1 User Manual

Warranty

3 Years

    Plug and Play, Rack Mountable, DIP Switch for Standard/Flow Control Off/VLAN/Extended Mode Selection

Out of stock

MODELO: GSW-1601
