Manageable 12-port 10/100/1000 Mbps 802.3at (Mid-span) high PoE HUB injector

Manageable 12-port 10/100/1000 Mbps 802.3at (Mid-span) high PoE HUB injector

Injects power to 12 High PoE devices through the same data cables.
Transmission and power distance up to 100m, up to 200m with POE-E201 extenders.

Protection:
-Auto-detects 802.3af/at High PoE devices, protecting equipment from damage due to improper installation.
-Circuit protection that prevents interference between ports.

Ports:
-12 10/100/1000Base-T Input Ports.
-12 10/100/1000Base-T Output Ports with High PoE 802.3af/at.
-1 10/100Base-TX Port for Management.
-Compatible with PoE 802.3af (15.4W) / High PoE 802.3at (30W) devices.

PoE Management:
-Intuitive Web Interface for Administration.
-Monitoring of Status and Power consumed by port.
-Monitoring of Total Power Consumed.
-Power limit per port and priority.
-PoE activation/deactivation per port.
-Supports SNMP Trap for alarm notification events.

Physical and Electrical Characteristics:
-Power supply: 100-240VAC @ 370W
-Total power: 340W.
-Dimensions: 1U Rack, 440 x 300 x 44 mm.
-Weight: 4.27Kg.
-Operating Temperature: 0 to 50°C



*2 Years Warranty.
