HELIAX 7/8" coaxial cable, corrugated copper, shielded, 50 Ohms

HELIAX 7/8" coaxial cable, corrugated copper, shielded, 50 Ohms

Electrical specifications:

• Impedance: 50 Ω.
• Outer Diameter: 28 mm.
• Speed ​​Factor: 91%.
• Attenuation at 30 meters UHF 450 MHz: 0.73 dB.
• Attenuation at 30 meters UHF 800 MHz: 0.99 dB.
• Internal Conductor Diameter (mm): 9.45.
• Insulation: Low density dielectric foam.
• Shielding: 100% solid corrugated copper.
• Weight per Meter (Kg): 0.45

*PRICE PER METER*

Differences against the AVA5-50

Solid center connector

Central connector resistance 2,888 ohms/km | 0.88 ohms/kft

External connector resistance 1.53 ohms/km | 0.466 ohms/kft

Speed ​​90%

Operating temperature -55 °C to +70 °C (-67 °F to +158 °F)

Storage temperature -70 °C to +70 °C (-94 °F to +158 °F)

Weight 0.41 kg/m | 0.276 lb/ft
