Base Station with Wireless IP Phone up to 300m, 5 SIP Accounts with up to 5 DP710 Phones per Base Station (Discontinued)

Base Station with Wireless IP Phone up to 300m, 5 SIP Accounts with up to 5 DP710 Phones per Base Station (Discontinued)

The DP715/710 is the next generation of power, affordability, high quality, and ease of use, the new DECT IP cordless phone. Its features such as compact size, excellent call quality, and
Voice, rich in features, market-leading price-performance, and wide radio coverage, allowing users to enjoy the benefits of mobility and Voice over IP with minimal investment. The DP715/710 is fully compatible with SIP/DECT standards and has been field-proven for flexible deployment.

BASE Specifications:
- 5 independent lines (SIP accounts) per DP710 phone or multiple DP710 phones per SIP account.
- Supports up to 5 DECT DP710 cordless phones (one included).
- Up to 4 simultaneous calls.
- Range: Up to 300 meters outdoors and 50 meters indoors.
- One 10/100Mbps auto-sensing RJ45 Ethernet port.

PHONE Specifications:
- 1.7” backlit FSTN LCD display with blue background.
- Battery life of 10 hours with active call and 80 hours on standby.

Phonebook:
200 records, each with up to 24 digits and up to 16 characters; record of the last 10 calls; record of 30 received calls.

Telephone functions:
Caller ID Activation or Blocking, Call Waiting, Blind or Assisted Transfer, Call Forwarding, Call Forwarding, Pause, Do Not Disturb, 3-Way Conference.

Codecs:
G.711 with Annex I (PLC) and Annex II (VAD/CNG), G.723.1, G.726-32 AAL2, G.729A/B, iLBC.

Security:
- TLS, SRTP, HTTPS.
- Web interface or secure (AES-encrypted) central configuration file for mass deployment; supports device configuration via IVR, Web browser, or central configuration file using TFTP, HTTP, or HTTPS.

Quality of service:
Layer QoS (802.1Q, 802.1P) and Layer 3 QoS (ToS, Di Serv, MPLS).

Languages:
Spanish, English, German, Italian, French, Portuguese, Russian, Croatian, Simplified and Traditional Chinese, Korean, Japanese.

Protocols and standards:
SIP RFC3261, TCP/IP/UDP, RTP/RTCP, HTTP/HTTPS, ARP/RARP, ICMP, DNS (A record, SRV, NAPTR), DHCP, PPPoE, SSH, TFTP, NTP, STUN, SIMPLE, LLDP-MED, LDAP, TR-069, 802.1x, TLS, SRTP

Accordance:
FCC Part 15B/15D; CE: ETSI EN 301 489-1 V1.8.1, ETSI EN 301 489-6 V1.3.1, ETSI EN 301 406-1 V2.1.1, ETSI EN 301 406 V1.5.1, EN60950-1, RoHs, UL (Power Supply).

Physical and electrical characteristics:
- Universal power supply; Input: 100-240VAC 50-60Hz; Output: 6VDC, 500mA.
- Dimensions: Base Station: 75 x 105 x 85 mm; Handset: 160 x 46 x 22 mm; Charger: 53 x 75 x 60 mm.
- Weight: Base Station: 95 g; Handset: 104 g; Charger: 102 g.
- Operating temperature: 0~40ºC.


Picture of the DP715 Base Station with its handset and 4 additional DP710 handsets in their charging stations:
