EPCOM TITANIUM

Active transceiver kit, sends 12V/24VDC/AC power, video and audio up to 150m in 4K for high definition video applications via Cat 5e/6 UTP.

Active transceiver kit, sends 12V/24VDC/AC power, video and audio up to 150m in 4K for high definition video applications via Cat 5e/6 UTP.

Regular price $57.273 COP
Regular price $62.643 COP Sale price $57.273 COP
Sale Sold out
Shipping calculated at checkout.

Active transceiver kit, sends 12V/24VDC/AC power, video and audio up to 150m in 4K for high definition video applications via Cat 5e/6 UTP.

TT-101PVA-TURBO

Active transceiver kit (Balum), sends 12V/24VDC/AC power, video and audio at a distance of up to 150 m in 4K

The TT-101PVA-TURBO is a transmitter and receiver that allows the transmission of voltage, HD video and audio in real time. The receiving equipment can be powered with voltages of 12/24 VDC / VAC, this allows us to reach great distances that can be up to 150 meters in 4k, the transmitter equipment provides us with the voltage supplied by the receiving equipment (consider the voltage drop). It is compatible with all analog HD-TVI, HD-CVI, AHD and CVBS cameras. It has a flexible mini-coaxial cable that allows quick mounting on cameras and allows flexible connection to DVRs. The TT-101PVA-TURBO has a built-in surge suppressor to protect video equipment against damaging voltage spikes, its immunity to noise and crosstalk ensure quality video signals.

...

Main Features:

  • Active transceiver kit, sends power, video and audio
  • Power transmission in 12 V / 24 Vdc / Vac
  • Compatible with cameras with HD-TVI / HD-CVI / AHD / CVBS technology
  • Supports Coaxitron, Coaxitron Audio and OSD menu
  • Real-time transmission over Cat 5e/6/6A UTP cable
  • Compatible with analog cameras (CVBS)
  • Built-in surge protection
  • Impedance 75 ohms
  • BNC male connectors

...

Physical and Electrical Characteristics:

  • It can be powered by 12/24 Vdc / Vac sources
    (Power supply NOT included)
  • Dimensions 60.4(L) x 29.0(W) x 20.4(H) mm (excluding BNC connector and cable)
  • Weight: 60 grams.
  • Operating temperature: -20°C to 70°C
  • Storage temperature: -40° ~ 150°C
  • Relative Humidity: 0~95% (non-condensing)
  • ABS housing
  • Black color.
  • 1 year warranty against manufacturing defects

...

Highlighted Features:

  • Anti-static wave filter design
  • Noise and crosstalk immunity of 60 dB.
  • Exceptional interference rejection
  • Built-in solid-state TVS (transient voltage suppressor).
  • 150 meter (492 ft) transmission for TurboHD in 4K
  • 200 meter (656 ft) transmission for TurboHD up to 5 MP
  • 250 meter (820 ft) transmission for TurboHD up to 2 MP
  • Note: The input voltage is the same as the output, consider the voltage drop
  • Price per Kit.

    Essential for your CCTV system

500 in stock

MODELO: TT-101-PVA-TURBO
