24-port 10/100/1000T Industrial Layer 3 Switch + 4 1000X SFP ports

24-port 10/100/1000T Industrial Layer 3 Switch + 4 1000X SFP ports

Powerful switch with Layer 3 routing for industrial environments.
Planet’s IGS-6330-24T4S is an industrial-grade rackmount Layer 3 switch specifically designed to form a full Gigabit backbone for reliably transmitting high-speed data in demanding industrial environments and for transmitting data to remote networks over fiber optics. It provides 24 10/100/1000BASE-T copper ports and 4 additional 1000BASE-X SFP ports, is IP30 rated, rugged, and has redundant power supplies, and supports Layer 3 features such as Static Routing, RIP v1/v2, OSPF v2, and VRRP for redundancy.


Ports:
24 10/100/1000BASE-T RJ45 Ports.
4 1000BASE-SX/LX/BX SFP Interfaces.

Performance:
41.6 Mpps (Millions of packets per second).

Layer 3 Functions:
Up to 8 VLAN interfaces.
RIP v1/v2, OSPF v2, VRRP.
IPV4 / IPV6 static routing.

Layer 2 Functions:
Port Configuration, Port Status, Port Mirroring, VLAN, Link Aggregation, QoS, IGMP Snooping, IGMP Querier supported, Access Control, Bandwidth Control, SNMP MIBs, SSH, SSL.

Administration:
Console, Telnet, Web interface. SNMP v1, v2c, v3.

Physical and electrical characteristics:
Power supply: 12~48 VDC, 20.8W.
Protection: 6KV DC ESD protection.
Operating temperature: -0 ~ 50ºC
Dimensions: 1U (Rack Unit) 440 x 253 x 44 mm.
Weight: 3.1 kg.


*3 Years Warranty.
