MIKROTIK
(NetMetal 5SHP) 5 GHz 802.11 a/n/ac 2x2 Connectorized Access Point, Up to 1260 mW of power.
(NetMetal 5SHP) 5 GHz 802.11 a/n/ac 2x2 Connectorized Access Point, Up to 1260 mW of power.
Couldn't load pickup availability
(NetMetal 5SHP) 5 GHz 802.11 a/n/ac 2x2 Connectorized Access Point, Up to 1260 mW of power.
This version of NetMetal is equipped with a super high power 1.3W 2x2 dual-chain 802.11a/n/ac wireless router and two RP-SMA connectors for external antennas.
NetMetal is an 802.11ac wireless device in a weatherproof metal housing. Its rugged design is built to withstand the harshest conditions, yet it's easy to use and can be opened and closed with one hand. The solid aluminum housing also acts as a reliable heat sink for its high-powered radio.
The NetMETAL is equipped with a powerful 720MHz CPU, 128MB of RAM, a Gigabit Ethernet port, 802.11ac wireless, an SFP slot, USB, RP-SMA connectors for external antennas, and a RouterOS L4 license. The case is sealed to meet the IP54 standard.
Specs
| Details | |
|---|---|
| Product code | RB921UAGS-5SHPacD-NM |
| Architecture | MIPSBE |
| CPU | QCA9557 |
| CPU core count | 1 |
| Nominal CPU frequency | 720 MHz |
| Dimensions | 143x247x48mm (PCB) |
| RouterOS License | 4 |
| Operating system | RouterOS |
| RAM size | 128 MB |
| Storage size | 128 MB |
| Storage type | NAND |
| Room temperature tested | -40°C to 70°C |
| MTBF | Approximately 200,000 hours at 25°C |
Feeding
| Details | |
|---|---|
| PoE in | Passive PoE |
| PoE in input voltage | 8-30 V |
| Number of DC inputs | 1 (PoE input) |
| Maximum energy consumption | 17 W |
| Fan count | Passive |
Wireless specifications
| Details | |
|---|---|
| Maximum wireless data rate of 5 GHz | 867 Mbit/s |
| Number of 5 GHz wireless chains | 2 |
| 5 GHz Wireless Standards | 802.11a/n/ac |
| 5GHz Wireless Chip Model | QCA9882 |
| 5 GHz wireless generation | Wi-Fi 5 |
Ethernet
| Details | |
|---|---|
| 10/100/1000 Ethernet ports | 1 |
Fiber
| Details | |
|---|---|
| SFP DDMI | Yeah |
| SFP ports | 1 |
Peripherals
| Details | |
|---|---|
| Number of USB ports | 1 |
| USB Power Reset | Yeah |
| USB slot type | USB Type A |
| Maximum USB current (A) | 1 |
Other
| Details | |
|---|---|
| PCB Temperature Monitor | Yeah |
| Voltage monitor | Yeah |
Share
Out of stock
MODELO: RB921UAGS-5SHPACD-NM
