Switch Administrable Capa 2 con Fuente de Alimentación Redundante, 24 Puertos SFP Gigabit 100/1000X, 8 Puertos Combo RJ45 Gigabit.

Layer 2 Managed Switch with Redundant Power Supply, 24 Gigabit 100/1000X SFP Ports, 8 Gigabit RJ45 Combo Ports.

Sale price  $3,164,155 Regular price  $3,168,477
Skip to product information
Switch Administrable Capa 2 con Fuente de Alimentación Redundante, 24 Puertos SFP Gigabit 100/1000X, 8 Puertos Combo RJ45 Gigabit.

Layer 2 Managed Switch with Redundant Power Supply, 24 Gigabit 100/1000X SFP Ports, 8 Gigabit RJ45 Combo Ports.

Sale price  $3,164,155 Regular price  $3,168,477
Shipping calculated at checkout.
Marca
PLANET
Referencia / SKU
GS-5220-16S8CR
Disponibilidad
Agotado por ahora
Descripción y especificaciones

Layer 2 Managed Switch with Redundant Power Supply, 24 Gigabit 100/1000X SFP Ports, 8 Gigabit RJ45 Combo Ports.

Effective alarm alert for better protection
They support a fault alarm function that can alert users when there is a problem with the switches. This feature allows users to identify the fault immediately, saving time and human resources.

Common application as a fiber routing switch for IP surveillance applications



Static VLAN Routing at Layer 2+

Hardware specifications
Copper Ports 8 x 10/100/1000Base-T RJ-45 Auto-MDI/MDI-X ports, shared with Port-1~Port-8
SFP/mini-GBIC slots 24 dual-speed 100/1000Base-X SFP interfaces
Console 1 RS-232 to RJ45 serial port (115200, 8, N, 1)
Performance 35.7Mpps@64Bytes
Address table 16,000
Dimensions 440 x 200 x 44.5 mm, height 1U
Weight 2745g
Energy requirements

100~240 V AC, 50/60 Hz

48V DC at 0.6A, Range: 36~60V

Energy consumption 45 Watts / 153 BTU (max.)
Layer 2 Functions Port Configuration, Port Status, Port Mirroring, VLAN, Link Aggregation, Spanning Tree Protocol, QoS, IGMP Snooping, MLD Snooping, Access Control List, Bandwidth Control
Layer 3 Functions IP Interfaces, Routing Table, Routing Protocols
Administration interfaces Console / Telnet / Web Browser / SNMP v1, v2c, SSH, SSL, SNMP v3
Operating temperature Temperature: 0 ~ 50 degrees C
Relative humidity: 5 ~ 95% (non-condensing)
Storage temperature. Temperature: -10 ~ 70 degrees C
Relative humidity: 5 ~ 95% (non-condensing)

    24 x 100/1000Base-X mini-GBIC/SFP slots, 8-port 10/100/1000Base-T RJ-45 Gigabit Ethernet, shared with Port 1 through Port 8, Layer 3 IP routing features, Redundant power system
