Tower Top Amplifier for 470-512 MHz, 2-3 MHz, 13.8 Vdc. N females.

Tower Top Amplifier for 470-512 MHz, 2-3 MHz, 13.8 Vdc. N females.

    Tower Top Amplifier, 470-512 MHz, 2-3 MHz, N Female.

• Excellent filtering before the LNA for system reception protection.
• Quadrature amplifier for improved reliability, lower noise and higher IP3.
• Low-loss filter, PolyPhaser® Bias-T discharge protection.
• Aluminum container design for lower wind load and better weather protection.
• Improved reception signal for long coaxial cabling.
• Automatic switching of the upper amplifier.
• The available test port option also requires a test port option on the PDU.
• Frequency range: 470-512 MHz.
• Filter bandwidth: 2-3 MHz.
• Gain: 16 dB.
• Noise Figure: 4.5 dB.
• IP3 Amplifier (Typical): 46 dBm.
• Return Loss (min.): 14 dB.
• Power: 15 Vdc.
• Operating current: 500 mA.
• Surge Suppression: 18 kA ANSI C62.1 8/20 Waveform 110 joules.
• Construction / Finish: Aluminum / White (UV Protection).
• Connector: N(F) 7/16 DIN available.
• Steel Structure for Environment: NEMA 4X.
• Mounting (included): 2-3 inch pipe mount.
• Temperature range: -30 ºC to 60 ºC.
• Dimensions (Width x Height x Depth): 292.1 x 793.8 x 337 mm.
• Net Weight / Shipping Weight: 22.7 / 27.3 kg.

*Ask for delivery time.
