• RouterBoard, CPU 2 Núcleos, 10 Puertos Gigabit Ethernet, 1 Puerto SFP, 1 GB Memoria, Licencia Nivel 5, Montaje Rack
1 5

MIKROTIK

RouterBoard, 2-Core CPU, 10 Gigabit Ethernet Ports, 1 SFP Port, 1 GB Memory, Level 5 License, Rack Mount

RouterBoard, 2-Core CPU, 10 Gigabit Ethernet Ports, 1 SFP Port, 1 GB Memory, Level 5 License, Rack Mount

$1.044.786 COP
$1.142.735 COP $1.044.786 COP
Sale Sold out
Shipping calculated at checkout.

RouterBoard, 2-Core CPU, 10 Gigabit Ethernet Ports, 1 SFP Port, 1 GB Memory, Level 5 License, Rack Mount

RB3011UiAS-RM

The RB3011 is a new multi-port device, the first to run an ARM-architecture CPU for higher performance than ever before. The RB3011 features ten Gigabit ports split across two switch groups, an SFP cage, and for the first time, a full-size SuperSpeed ​​USB 3.0 port for adding storage or an external 3G/4G modem.

The RB3011UiAS-RM unit comes with a 1U rackmount enclosure, a touchscreen LCD panel, a serial console port, and PoE output functionality on the last Ethernet port.

RouterBOARD Architecture: ARM
Important Note:
Architecture Type Not Compatible with User Manager.
Experimental support for SMIPS, ARM and MMIPS architectures (RB1100AHx4, RB3011, RB750Gr3 etc.) will be available starting with version 6.42rc14.


Main features of RouterOS

General Specifications

Details
Product Code RB3011UiAS-RM
Architecture ARM 32bit
CPU IPQ-8064-0-519FCBGA-TR-01-0
Number of CPU Cores 2
CPU frequency 1.4 GHz
Dimensions 443x92x44mm
License Level 5
Operating System RouterOS
RAM memory 1 GB
Storage 128 MB
Storage Type NAND
Temperature -30 + 70 C

Feeding

Details
Energy consumption 10W
Power Supplies 2 (DC jack, PoE-IN)
Power Type PoE Passive PoE
Jack input voltage 10-30 V DC
PoE input voltage 10-30 V DC
PoE Output Passive PoE

Ethernet

Details
Ethernet ports 10 x 10/100/1000 Mbps

Optical fiber

Details
SFP ports 1

Peripherals

Details
Number of USB ports 1
Serial Port (Console) RJ45
USB port power reset Yeah
USB port type USB 3.0 Type A

Others

Details
PCB Temperature Monitor Yeah
Voltage Monitor Yeah

Ethernet Test Results

RB3011UiAS-RM IPQ-8064 All port test
Mode Configuration 1518 bytes 512 bytes 64 bytes
kpps Mbps kpps Mbps kpps Mbps
Bridging none (fast path) 325.0 3,946.8 939.8 3,849.4 1,530.2 783.5
Bridging 25 bridge filter rules 325.0 3,946.8 384.2 1,573.7 348.6 178.5
Routing none (fast path) 325.0 3,946.8 939.8 3,849.4 1,437.6 736.1
Routing 25 simple queues 325.0 3,946.8 419.6 1,718.7 419.7 214.9
Routing 25 IP filter rules 202.0 2,453.1 204.1 836.0 188.4 96.5
  1. All tests are done with Xena Networks specialized test equipment (XenaBay), and done according to RFC2544 (Xena2544)
  2. Max throughput is determined with 30+ second attempts with 0.1% packet loss tolerance in 64, 512, 1518 byte packet sizes
  3. Values ​​in Italic indicate that max throughput was reached without maxing out CPU, but because board interface configuration was maxed out
  4. Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results


Parts Included


*Images are for illustrative purposes only

How to avoid False Contact Problem


    1.4GHz Dual Core ARM Processor, 1GB RAM, 10x 10/100/1000Mbps Ports, 1x SFP Port, 1x USB 3.0 Port, LCD, Rack Mount, Power: DC Jack or Passive PoE, License Level: 5
