(hAP ac) 5 Gigabit Ethernet Ports, 1 SFP Port, 1 USB, 3x3 802.11ac Dual Band WiFi, up to 1W of power
(hAP ac) 5 Gigabit Ethernet Ports, 1 SFP Port, 1 USB, 3x3 802.11ac Dual Band WiFi, up to 1W of power
Couldn't load pickup availability
(hAP ac) 5 Gigabit Ethernet Ports, 1 SFP Port, 1 USB, 3x3 802.11ac Dual Band WiFi, up to 1W of power
The hAP ac is our most versatile and comprehensive home and small office device. It's a dual-band device with Gigabit ports that deliver all the speed benefits of 802.11ac technology, while maintaining compatibility with legacy devices in 2GHz 802.11 b/g/n and 5GHz a/n operating modes .
Omnidirectional antennas allow the AC HAP to be mounted anywhere, and the high-power transmitter will ensure good coverage for mobile devices in your home, office, or public place.
Other useful features include a USB port for connecting additional storage or a 3G/4G modem, PoE output on the last Ethernet port, providing power to other RouterBoard devices without the need for an extra power adapter, and an SFP port, for connecting active or passive optical network modules.
*1 year warranty.
Main features of RouterOS
Solution to connect 3G device to a LAN network.
Tests carried out with BAMs
Brand: Huawei Model: E153u-6
Brand: Huawei Model: E1556
Brand: Huawei Model: E3372
​Brand: Nokia Model: CS-11
Brand: ZTE Model: MF100
**Not Compatible Models
Brand: TCT Mobile Model: X602A
Brand ZTE Model: MF180
Brand ZTE Model: MF626
| Product code | RB962UiGS-5HacT2HnT |
| CPU nominal frequency | 720 MHz |
| CPU number of cores | 1 |
| RAM size | 128 MB |
| 10/100/1000 Ethernet ports | 5 |
| wireless chip model | QCA9880 |
| Wireless standards | 802.11a/n/ac |
| secondary wireless chip model | QCA9558 |
| Number of USB ports | 1 |
| Power connector | 1 |
| input voltage support | 11 V - 57 V |
| PoE out | Yeah |
| PoE | Yeah |
| Voltage monitor | Yeah |
| PCB temperature monitoring | Yeah |
| Dimensions | 114 x 137 x 29 mm |
| Operating system | RouterOS |
| license level | 4 |
| Antenna gain DBI | 2 |
| UPC | QCA9558 |
| Maximum energy consumption | 17W |
| SFP ports | 1 |
| USB slot type | USB Type A |
| Number of chains | 3 |
| storage type | FLASH |
| The storage size | 16 MB |
Wireless specifications
| 2.4 GHz | |||
|---|---|---|---|
| Transmit (dBm) | Receive Sensitivity | ||
| 1MBit/s | 29 | -100 | |
| 11MBit/s | 29 | -94 | |
| 6MBit/s | 29 | -96 | |
| 54MBit/s | 26 | -81 | |
| MCS0 | 29 | -96 | |
| MCS7 | 25 | -77 | |
Ethernet test results
| RB962UiGS-5HacT2HnT | QCA9558 1G all-port test | ||||||
| Mode | Configuration | 1518 bytes | 512 bytes | 64 bytes | |||
| kpps | Mbps | kpps | Mbps | kpps | Mbps | ||
| Bridging | none (fast path) | 161.9 | 1,966.1 | 345.5 | 1,415.2 | 435.6 | 223.0 |
| Bridging | 25 bridge filter rules | 125.5 | 1,524.1 | 126.5 | 518.1 | 128.8 | 65.9 |
| Routing | none (fast path) | 161.9 | 1,966.1 | 334.2 | 1,368.9 | 397.9 | 203.7 |
| Routing | 25 simple queues | 161.9 | |||||
Out of stock
MODELO: RB962UIGS-5HACT2HNT
