(mANTBox 19s) 120º Sector Access Point in 5GHz AC (5.17 - 5.825GHz), Integrated 19 dBi Antenna, Up to 1000 mW, Dual Power Supply
(mANTBox 19s) 120º Sector Access Point in 5GHz AC (5.17 - 5.825GHz), Integrated 19 dBi Antenna, Up to 1000 mW, Dual Power Supply
Couldn't load pickup availability
(mANTBox 19s) 120º Sector Access Point in 5GHz AC (5.17 - 5.825GHz), Integrated 19 dBi Antenna, Up to 1000 mW, Dual Power Supply
The mANTBox is based on our new mANT sector antennas, but also has a built-in wireless router. Powered by the RB921 device, the mANTBox comes ready to use with everything included. The device uses a high-speed 720MHz CPU and has an integrated 802.11ac/a/n wireless router with an output power of up to 31dBm.
mANTBox 19s comes with a 19dBi 120-degree sector antenna.
We have two versions available: RB921GS-5HPacD-19S (International) and RB921GS-5HPacD-19S-US (US). RB921GS-5HPacD-19S-US (US) is factory locked to 5.17-5.25 GHz and 5.725-5.835 GHz frequencies. This lock cannot be removed. RB921GS-5HPacD-19S (International) supports the 5.17 - 5.835 GHz range (specific frequency range may be limited by country regulations).
Specs
| Details | |
|---|---|
| Product code | RB921GS-5HPacD-19S |
| Architecture | MIPSBE |
| CPU | QCA9557 |
| CPU core count | 1 |
| Nominal CPU frequency | 720 MHz |
| Dimensions | 152 x 598 x 78 mm |
| RouterOS License | 4 |
| Operating system | RouterOS |
| RAM size | 128 MB |
| Storage size | 128 MB |
| Storage type | NAND |
| Room temperature tested | -40°C to 70°C |
| MTBF | Approximately 200,000 hours at 25°C |
Feeding
| Details | |
|---|---|
| PoE in | Passive PoE |
| PoE in input voltage | 12-28 V |
| Number of DC inputs | 2 (DC jack, PoE-IN) |
| DC jack input voltage | 8-30 V |
| Maximum energy consumption | 13 W |
| Fan count | Passive |
Wireless specifications
| Details | |
|---|---|
| Maximum wireless data rate of 5 GHz | 867 Mbit/s |
| Number of 5 GHz wireless chains | 2 |
| 5 GHz Wireless Standards | 802.11a/n/ac |
| Antenna gain dBi for 5 GHz | 19 |
| 5GHz Wireless Chip Model | QCA9892 |
| 5 GHz wireless generation | Wi-Fi 5 |
Ethernet
| Details | |
|---|---|
| 10/100/1000 Ethernet ports | 1 |
Fiber
| Details | |
|---|---|
| SFP ports | 1 |
Other
| Details | |
|---|---|
| PCB Temperature Monitor | Yeah |
| Voltage monitor | Yeah |
Certifications and approvals
| Details | |
|---|---|
| Certification | CE, FCC, IC, EAC, ROHS |
Wireless specifications
| 5 GHz |
|---|
Out of stock
MODELO: RB921GS-5HPACD-19S
