EPCOM TITANIUM
TURBO HD active transceiver kit. Converts 36/24 VDC to regulated 12 VDC via Cat5e/6 UTP cable. 200 m transmission range in 3K.
TURBO HD active transceiver kit. Converts 36/24 VDC to regulated 12 VDC via Cat5e/6 UTP cable. 200 m transmission range in 3K.
Couldn't load pickup availability
TURBO HD active transceiver kit. Converts 36/24 VDC to regulated 12 VDC via Cat5e/6 UTP cable. 200 m transmission range in 3K.
TT4816PVTURBO
Active transceiver kit (Balum), regulates voltage from up to 36 Vdc to 12 Vdc
The TT-4816-PVTURBO is a transmitter and receiver that allows the transmission of voltage and the HD video signal in real time. The receiving equipment can be powered with 24/36 voltages, this allows us to reach great distances that can be up to 200 meters in 4k, the transmitter equipment can regulate the voltage to 12 Vdc, a very common operating voltage in CCTV cameras. It is compatible with all analog HD-TVI, HD-CVI, AHD and CVBS cameras. It has a flexible mini-coaxial cable that allows quick mounting on cameras and allows flexible connection with DVRs. TT-4816-PVTURBO has an integrated surge suppressor to protect video equipment against damaging voltage spikes, its immunity to noise and crosstalk ensure quality video signals.
Main Features:
- Active Transceiver Kit
- Power supply to the receiver of up to 36 Vdc
- Voltage regulator in the transmitter to 12 Vdc.
- Compatible with cameras with HD-TVI / HD-CVI / AHD / CVBS technology
- Compatible with analog cameras (CVBS)
- Supports Coaxitron, Coaxitron Audio and OSD menu
- Real-time transmission over Cat 5e/6/6A UTP cable
- Built-in surge protection
- Impedance of 75 ohms
- BNC male connectors
Physical and Electrical Characteristics:
-
It can be powered by 24/36 Vdc sources(Power supply NOT included)
- Dimensions 60.4(L) x 29.0(W) x 20.4(H) mm (excluding BNC connector and cable)
- Weight: 60 grams.
- Operating temperature: -20°C to 70°C
- Storage temperature: -40° ~ 150°C
- Relative Humidity: 0~95% (non-condensing)
- ABS housing
- Black color.
- 1 year warranty against manufacturing defects
Highlighted Features:
- Anti-static wave filter design
- Noise and crosstalk immunity of 60 dB.
- Exceptional interference rejection
- Built-in solid-state TVS (transient voltage suppressor).
- 150 meter (492 ft) transmission for TurboHD in 4K
- 200 meter (656 ft) transmission for TurboHD up to 5 MP
- 250 meter (820 ft) transmission for TurboHD up to 2 MP
- The transmitter is compatible with the kits: KIT-TT4PVTURBOX, KIT-TT8PVTURBOX, KIT-TT16PVTURBOX
- Price per Kit.
- Essential for your CCTV system
500 in stock
MODELO: TT-4816-PVTURBO
View full details
