6-Line Mid-Range IP Phone with 4 Feature Keys, 24 Digital BLF Extension Keys, and 5-Way PoE Conferencing

6-Line Mid-Range IP Phone with 4 Feature Keys, 24 Digital BLF Extension Keys, and 5-Way PoE Conferencing

The GXP1760 is a mid-range IP phone with a sleek new design and moderate call volume features. It comes equipped with six lines, three SIP accounts, six dual-color line keys, and four context-sensitive programmable XML keys on a 200 x 80 pixel backlit LCD display. For additional customization, the GXP1760 offers custom ringtone/ringback tone music and integration with advanced web and business applications, as well as local weather. It is also one of the first phones

Grandstream comes equipped with a Kensington security lock, one of the most popular anti-theft solutions on the market. The GXP1760 supports the fastest possible connection speeds with two auto-sensing 10/100Mbps network ports, as well as auto-provisioning features with media access control. This mid-range IP phone offers excellent performance and design to users worldwide at a budget-friendly price.

Main:

- 6 Lines, 3 SIP accounts, 4 programmable XML function keys and 5-way conferencing.

- 24 Digitally programmable BLF extension keys.

- 200 x 80 Pixelex LCD display with backlight

- HD Audio.

- Dual 10/100 Mbps network ports.

Telephone functions:

Hold, transfer, forward, 5-party conference,

Call park, call retrieve, call status

Shared Access (SCA)/Bridged Line Status (BLA), Phonebook

Downloadable (XML, LDAP, up to 2000 contacts), call waiting, logging

Call logs (up to 500 records), XML screen customization,

Auto redial on pick up, auto answer, click to

dialing, flexible dialing plan, hot desking (workstations

shared), ringtones with personalized music and music in

standby, server redundancy and failover

Codecs:

Support for G.729A/B, G.711μ/a-law, G.726, G.722 (broadband), G.723,

iLBC, OPUS, in-band and out-of-band DTMF (in audio, RFC2833, SIP INFO)

Interfaces:

Two auto-sensing 10/100Mbps switched Ethernet ports

with integrated POE

Security:

User and administrator level passwords, authentication based on

MD5 and MD5-sess, 256-bit AES encrypted configuration file,

SRTP, TLS, 802.1x Media Access Control, Security Sockets support

Kensington (Kensington Lock)

Quality of service:

Layer 2 QoS (802.1Q, 802.1P) and Layer 3 (ToS, DiffServ, MPLS) QoS

Languages:

Spanish, English, German, Italian, French, Portuguese, Russian, Croatian, Simplified and Traditional Chinese, Korean, Japanese.

Protocols and standards:

SIP RFC3261, TCP/IP/UDP, RTP/RTCP, HTTP/HTTPS, ARP, ICMP, DNS (A record,

SRV, NAPTR), DHCP, PPPoE, TELNET, TFTP, NTP, STUN, SIMPLE, LLDP, LDAP,

TR-069, 802.1x, TLS, SRTP, IPV6 .

Accordance:

FCC: Part 15 (CFR 47) Class B

CE: EN55022 Class B; EN55024 Class B; EN61000-3-2; EN61000-3-3;

EN60950-1

RCM: AS/ACIF S004; AS/NZS CISPR22/24; AS/NZS 60950.1

Physical and electrical characteristics:

- Universal power supply; Input: 100~240VAC 50-60Hz; Output: .5VDC, 1A. / PoE 802.3af .

- Base or wall mountable.

- Dimensions: 167 x 231 x 86 mm.

- Weight: 0.925 kg.

- Operating temperature: 0~40ºC.

Package contents:

GXP1760 Phone, Corded Handset, Stand, Power-over-Ethernet, Network Cable, Quick Reference Guide.

*1 year warranty.
