Transceptor WDM mini-Gbic SFP 1G LC TX:1310nm RX:1550 para fibra Mono Modo 20 Km, (Requiere MGB-LB20)

1G SFP mini-Gbic WDM transceiver LC TX:1310nm RX:1550 for 20km single-mode fiber (Requires MGB-LB20)

Sale price  $127,187 Regular price  $156,935
Skip to product information
Transceptor WDM mini-Gbic SFP 1G LC TX:1310nm RX:1550 para fibra Mono Modo 20 Km, (Requiere MGB-LB20)

1G SFP mini-Gbic WDM transceiver LC TX:1310nm RX:1550 for 20km single-mode fiber (Requires MGB-LB20)

Sale price  $127,187 Regular price  $156,935
Shipping calculated at checkout.
Marca
PLANET
Referencia / SKU
MGB-LA20
Disponibilidad
Agotado por ahora
Descripción y especificaciones

1G SFP mini-Gbic WDM transceiver LC TX:1310nm RX:1550 for 20km single-mode fiber (Requires MGB-LB20)

The MGB family consists of small form-factor pluggable (SFP) transceiver modules specifically designed for high-performance, integrated duplex data links over single-mode optical fiber. These transceiver modules are SFP Multi-Source Agreement (MSA) compliant and hot-pluggable. These modules offer easy installation into SFP MSA-compliant ports at any time without disrupting host equipment operation.

SFP transceivers are hot-pluggable and hot-swappable. You can plug and unplug the transceivers into/out of any SFP port without having to power down the switch/media converter.

MGB-LA20 and MGB-LB20
Type MGB IEEE 802.3z 1000BASE-BX
Fiber type Singular mode
Connector LC/UPC simplex
DDM Yeah
Wavelength MGB-LA20: TX1310nm, RX1550nm
MGB-LB20: TX1550nm, RX1310nm
Maximum distance 20 kilometers
Operating temperature 0~60 degrees C

** This model requires working in conjunction with the model: MGB-LB20

    Compliant with IEEE 802.3ab/802.3z Gigabit Ethernet, One 1000Mbps TP/LC fiber port, Duplex/Simplex LC connector, PECL differential inputs and outputs, Single 3.3V power supply, TTL signal detection indicator, Hot-pluggable, Class 1 laser product complies with EN 60825-1, Plug and Play installation
