UTM Firewall Router, SD-WAN & Wireless Controller (AWC), with 2 Gigabit WAN Combo Ports + 8 Gigabit LAN Ports

UTM Firewall Router, SD-WAN & Wireless Controller (AWC), with 2 Gigabit WAN Combo Ports + 8 Gigabit LAN Ports

Ports:

2 Gigabit SFP WAN ports / 2 10/100/1000 Mbps RJ45 Combo ports.

8 10/100/1000 Mbps LAN ports.

Operating System:

AlliedWare Plus™.

Administration:

Command Line Interface (CLI).

Graphical user interface (GUI).

SSH.

SNMP v2 & v3 monitoring.

Processor and memory:

1.5GHz quad-core.

2GB RAM.

4GB Flash.

Characteristics:

Deep Packet Inspection (DPI) Firewall*.

Application and web control*.

URL filtering*.

Intrusion Detection / Prevention System (IDS/IPS)*.

IP reputation*.

Malware protection*.

Antivirus*.

Site-to-site VPN (IPSec) 200.

Client-to-site VPN (OpenVPN) 1000.

*Note: Licensing is required for the NGFW portion.

AWC Wireless Controller.

Highly cost-effective solution for wireless SMB control.

Manage up to 5 access points (APs) for free, with an additional 20 available through a separate software license.

Wireless networks can have separate SSID, VLAN, and Security.

Physical and Electrical Characteristics:

Power supply: 90-260 VAC, 47-63Hz.

Dimensions: 1 U Rack, 42.5 x 210 x 220 mm.

Weight: 1.7 kg.

Operating Temperature: 0 to 45° C.

Warranty:

1 year.

http://www.alliedtelesis.com/support/maintenance-and-warranty/register

Example of a key solution.

Integrated protection and secure remote access. This solution features a firewall that provides site-to-site IPSec VPN connectivity between corporate offices while also providing secure access to remote workers.

Example of a Wireless solution.

Allied Telesis AWC offers solutions to the most common wireless network problems, where the complexity of initial configuration degrades performance.

Virtual Private Network (VPN): IPSec and L2TP, 3G/4G/LTE USB Modem, Routing: RIP, OSPF, BGP, RIPng, OSPFv3, BGP4+, UTM and SD-WAN, (AMF) automates backups for plug-and-play recovery, Concurrent sections: 300,000
