High Performance Dielectric., OFNR Riser, Optical Fiber Cable for Indoor, Tight Buffer 900 µm, 12 cores

The IC-RISER-A2-12C fiber optic cable is designed for horizontal and vertical indoor installations as it has a Riser fire retardant jacket (OFNR). Fiber strands meet G.657A2 classification to support a small bend radius for routing within manifolds, manholes, or tubing.

• Optical Fiber singlemode cable G.657A2
• Tight Buffer (900 µm)
• Sheath: OFNR Riser/LSZH
• Tensile Max: 600 N
• Operation Temperature Range: -10ºC ～ +60ºC
• Storage Temperature Range: -20ºC ～ +60ºC
• Nominal cable diameter: 6.5 ± 0.5 mm
• 12 cores
